- General
- Core Color1 White- Blue /Blue 2 White-Orange /Orange 3 White- Green /Green 4 White- Brown /Brown
- PackingWooden Tray & Carton
- Carton DimensionPer request
- Packing Length(305±0.5)m
- Rip-CordYes
- Drain WireNo
- Sheath Physical Properties
Before Aging Tensile Strength (Mpa) ≥10 Elongation(%) ≥300
Aging Period(℃×hrs) 100℃×24h×10d
After Aging Tensile Strength(Mpa) ≥12.5 Elongation(%) ≥125
Cold bend(-20±2℃×4h) 8×Cable O.D.，No visible cracks
- Electrical Characteristics (20℃)
1.0-100.0MHz Impedance(Ω) 100±15
1.0-100.0MHz Delay Skew (ns/100m) ≤552
DC Resistance(Ω/100m) max 9.5
DC Conductor Resistance Unbalance(%) max 2.0
- Conductor
- MaterialSolid-Bare Copper Content 99.99%
- Nom.O.D.(Mm)0.5±0.01
- Insulation
- MaterialHDPE
- Diameter0.88±0.03mm
- Sheath
- Thickness0.55±0.03 mm
- External O.D.5.0±0.3 mm
- SurfaceClean, Frap, Satiation
- MaterialPE
- ColorBlack
- Surface Printing
- Letter Height2.8mm
- ColorWhite
- Print Error & Space≤±0.5%，1m
|
|
