Technical Spec
| System Board¹ | Mini-ITX / Micro-ATX / ATX / E-ATX |
| Case Type | Middle Tower |
| Product Dimensions | 442X210X479mm |
| Carton Dimensions | 515X275X510mm |
| Net Weight | 7.31Kg |
| Gross Weight | 8.6Kg |
| Materials | ABS+SPCC+Tempered Glass |
| 3.5" Drive Bays | 2 |
| 2.5" Drive Bays | 2+2 |
| External 3.5'' Drive Bays | 0 |
| 5.25" Drive Bays | 0 |
| Power Supply Type | ATX PS2 (Length less than 170mm) |
| I/O Ports | USB2.0×2、USB3.0×1、Audio×1、Mic×1 |
| Expansion Slots | 7 Slots |
| Cooling Fans Support | Pre-installed: Front:120×3mm LED fan; Rear:120mm x1 LED fan；Front:140mm×3/120mm×3; Top:140mm×2/120mm×2；Rear：120mm×1 |
| Liquid Cooler Support | Front: 120/140/240/280/360mm; Top: 120/140/240mm ; Rear: 120mm |
| CPU Cooler Height Limit | 160 mm |
| VGA Length Limit | 370mm Horizontal/340mm Vertical |
| Cable Management | 24mm clearance |
| EAN Code | 6933412714729 |
| PN Code | DP-ATX-MATREXX50-M |
|
|
