| Model Parameters |
|---|
| Model | CS-CV310-A0-1B2WFR |
|---|
| Camera |
|---|
| Image Sensor | 1/2.7” Progressive Scan CMOS |
|---|
| Minimum Illumination | 0.02 lux @(F2.0, AGC ON), 0 lux with IR |
|---|
| Shutter Speed | Self-adaptive shutter |
|---|
| Lens | 2.8mm@ F2.2, Horizontal angle: 103° Diagonal angle: 118° 4mm@ F2.0, Horizontal angle: 87° Diagonal angle: 104° 6mm@ F2.0, Horizontal angle: 54° Diagonal angle: 62° |
|---|
| Lens Mount | M12 |
|---|
| Day & Night | IR-cut filter with auto-switching |
|---|
| DNR | 3D DNR |
|---|
| WDR | Digital WDR |
|---|
| Compression |
|---|
| Video Compression | H.264 |
|---|
| H.264 Type | Main profile |
|---|
| Video Bit Rate | HD, Balanced and Smooth. Adaptive bit rate. |
|---|
| Image |
|---|
| Max. Resolution | 1920×1080 |
|---|
| Image setting | Brightness, contrast, saturation, etc. (configurable via EZVIZ Studio) |
|---|
| BLC | Support |
|---|
| Network |
|---|
| Storage | Support Micro SD card (Max. 128G) |
|---|
| Smart Alarm | Intelligent motion detection |
|---|
| Wi-Fi Pairing | SmartConfig (Wi-Fi One-Key Configuration)/AP paring |
|---|
| Protocol | EZVIZ cloud proprietary protocol |
|---|
| Interface Protocol | EZVIZ cloud proprietary protocol |
|---|
| General Features | Anti-Flicker, Dual-Stream, Heartbeat Messages, Mirror Image, Password Protection, Watermark |
|---|
| Communication Interface | RJ45 10M/100M self-adaptive Ethernet port*1 |
|---|
| Minimum Network Requirements | 2Mbps |
|---|
| Wi-Fi |
|---|
| Standard | IEEE802.11 b/g/n |
|---|
| Frequency Range | 2.4 GHz ~ 2.4835 GHz |
|---|
| Channel Bandwidth | Supports 20MHz |
|---|
| Security | 64/128-bit WEP, WPA/WPA2, WPA-PSK/WPA2-PSK |
|---|
| Transmission Rate | 11b: 11Mbps, 11g: 54Mbps, 11n: 150Mbps |
|---|
| General |
|---|
| Operating Conditions | -30°C ~ 60°C, Humidity 95% or less (non-condensing) |
|---|
| Power Supply | DC 12V±10% |
|---|
| Power Consumption | Max. 6W |
|---|
| IP Grade | IP66 |
|---|
| IR Range | Max. 30meters |
|---|
| Product Dimensions | 150.44mm x 85.80mm x 71.64mm |
|---|
| Packaging Dimensions | 252mm x 110mm x 92mm |
|---|
| Weight | 326g |
|---|
